Redtronic Motorcycle Switch PN: MBS-1
Part Number: MBS1
Redtronic Motorcycle Switch PN: MBS-1 is a specialized, handlebar-mounted controller designed specifically for emergency service and enforcement motorcycles
excl. VAT £146.23
(incl. VAT £175.48)
(incl. VAT £175.48)
Redtronic Motorcycle Switch PN: MBS-1
Part Number: MBS1
Redtronic Motorcycle Switch PN: MBS-1 (Motorcycle Switch Control Unit) is a specialized, handlebar-mounted controller designed specifically for emergency service and enforcement motorcycles. It provides riders with a central, easy-to-reach interface to operate vehicle warning lights and sirens without removing their hands from the grips.
Technical Specifications
Operating Voltage: 12V DC only.
Switching Configuration: Negative-tripped (ground switched) switches. (Note: Redtronic also manufactures an MBS-2 variant for positive-tripped systems).
Mounting: Attaches directly to standard motorcycle handlebars.
Warranty: 1-year manufacturer warranty.
Switch Layout & Functionality
The MBS-1 utilizes a 4-way master switch architecture coupled with an auxiliary trigger to cycle emergency modes sequentially:
Position 1: Simultaneous activation of all warning lights and sirens.
Position 2: Warning lights activation only (siren muted for silent approach).
Position 3: System Deactivated (All systems OFF).
Position 4: Auxiliary function activation (commonly mapped to stationary "Rear Reds" or matrix signs).
Yellow Switch: Tone Cycle (Allows manual overriding or cycling of siren tones).
Technical Specifications
Operating Voltage: 12V DC only.
Switching Configuration: Negative-tripped (ground switched) switches. (Note: Redtronic also manufactures an MBS-2 variant for positive-tripped systems).
Mounting: Attaches directly to standard motorcycle handlebars.
Warranty: 1-year manufacturer warranty.
Switch Layout & Functionality
The MBS-1 utilizes a 4-way master switch architecture coupled with an auxiliary trigger to cycle emergency modes sequentially:
Position 1: Simultaneous activation of all warning lights and sirens.
Position 2: Warning lights activation only (siren muted for silent approach).
Position 3: System Deactivated (All systems OFF).
Position 4: Auxiliary function activation (commonly mapped to stationary "Rear Reds" or matrix signs).
Yellow Switch: Tone Cycle (Allows manual overriding or cycling of siren tones).
