LED Global 102W LED High & Low Beam Headlight with DRL PN: LG831
LG831
102 Watt LED High & Low Beam Headlight with DRL, 5760 Lumen - LG831
excl. VAT £78.30
(incl. VAT £93.96)
(incl. VAT £93.96)
102 Watt LED High & Low Beam Headlight with DRL, 5760 Lumen - LG831
General Characteristics
Housing: Powder Coated Aluminium
60w High Beam
30w Low Beam
12w DRL ( Daytime Running Light)
9/32V
50,000h
E Mark Certified
IP68
ECE R10, ECE R112, ECE R148 Approved
EMC - CISPR25 Class 4 (Radio Frequency Suppression)
Supplied With H4 Plug & Play Connection
Dimensions 165 x 107 x 80mm
Technical Light Properties
Light colour: Cold white
Ireland / UK Headlight
Colour temperature: 6000K
ELECTRICAL CHARACTERISTICS
Nominal lamp power: 60 Watt
60W high-intensity CREE XTE LEDs
Suitable for 9-32V DC
5,760 lumens
Lux Reading: 50Mtr @ 12Lux
Lux Reading: 186Mtr @ 1Lux
Vibration Test to 15G
DIMENSIONS IN MM.
Lamp width: 165 mm
Lamp height: 107 mm
Lamp thickness: 80 mm
*O.E.M Ref:
JOHN DEERE : AL75338 & RE56964,
MASSEY FERGUSON :1693943M93,
LANDINI :1693943M93 & 3542817M91 & 1333291C1
NEW HOLLAND: 81869794, 83999518, F0NN13006AB,
DAVID BROWN K300208,
HELLA: 003177001,HELLA: 1AB003177006
AGCO X830160039000, BMW 4188712,BOSCH 0301709100,
CASE IH 1333291C1,CASE IH 7723461,CATERPILLAR 772346
FAUN 99707723461,FENDT X830160039000,HELLA 1AB003177007,HELLA 1AB003177008,HELLA 1AB006277087
HELLA 1AB006277088,JOHN DEERE AL75338,JOHN DEERE RE56964,JOHN DEERE AZY75360,KLOKKERHOLM 96000250
LANDINI 1333291C1,MACK 438179566,TRIFA 7358935,VALEO 082395,DAVID BROWN K300208
SUPERSEDES ORIGINAL NUMBER:
John Deere: AL152328, AL152329, RE269110
CASE: 1333291C1, 85651C91
DEUTZ: 21/181-74, 20/181-22
NH 82014422
NH 82014423
COMPATIBLE WITH THE FOLLOWING:
John Deere
5070 M 5080 M 5080 R 5085 M 5090 M 5090 R (To 2014) , JD 5100 M , JD 5100 R (Until 2014) , 5620 , 5720 , 5820
AL152328, RE269110,AL152329
*Original Equipment names, series numbers & images are quoted and shown for reference purposes only and are not intended to infer that our replacement parts are used as original equipment
General Characteristics
Housing: Powder Coated Aluminium
60w High Beam
30w Low Beam
12w DRL ( Daytime Running Light)
9/32V
50,000h
E Mark Certified
IP68
ECE R10, ECE R112, ECE R148 Approved
EMC - CISPR25 Class 4 (Radio Frequency Suppression)
Supplied With H4 Plug & Play Connection
Dimensions 165 x 107 x 80mm
Technical Light Properties
Light colour: Cold white
Ireland / UK Headlight
Colour temperature: 6000K
ELECTRICAL CHARACTERISTICS
Nominal lamp power: 60 Watt
60W high-intensity CREE XTE LEDs
Suitable for 9-32V DC
5,760 lumens
Lux Reading: 50Mtr @ 12Lux
Lux Reading: 186Mtr @ 1Lux
Vibration Test to 15G
DIMENSIONS IN MM.
Lamp width: 165 mm
Lamp height: 107 mm
Lamp thickness: 80 mm
*O.E.M Ref:
JOHN DEERE : AL75338 & RE56964,
MASSEY FERGUSON :1693943M93,
LANDINI :1693943M93 & 3542817M91 & 1333291C1
NEW HOLLAND: 81869794, 83999518, F0NN13006AB,
DAVID BROWN K300208,
HELLA: 003177001,HELLA: 1AB003177006
AGCO X830160039000, BMW 4188712,BOSCH 0301709100,
CASE IH 1333291C1,CASE IH 7723461,CATERPILLAR 772346
FAUN 99707723461,FENDT X830160039000,HELLA 1AB003177007,HELLA 1AB003177008,HELLA 1AB006277087
HELLA 1AB006277088,JOHN DEERE AL75338,JOHN DEERE RE56964,JOHN DEERE AZY75360,KLOKKERHOLM 96000250
LANDINI 1333291C1,MACK 438179566,TRIFA 7358935,VALEO 082395,DAVID BROWN K300208
SUPERSEDES ORIGINAL NUMBER:
John Deere: AL152328, AL152329, RE269110
CASE: 1333291C1, 85651C91
DEUTZ: 21/181-74, 20/181-22
NH 82014422
NH 82014423
COMPATIBLE WITH THE FOLLOWING:
John Deere
5070 M 5080 M 5080 R 5085 M 5090 M 5090 R (To 2014) , JD 5100 M , JD 5100 R (Until 2014) , 5620 , 5720 , 5820
AL152328, RE269110,AL152329
*Original Equipment names, series numbers & images are quoted and shown for reference purposes only and are not intended to infer that our replacement parts are used as original equipment
