Lazer Lamps Ford Transit Custom 'Trail Edition' (2018-2022) Triple-R 750 Bumper Beam Mounting Kit PN: VIFK-FTC-02K
For an OE quality, robust and entirely secure auxiliary spotlight installation, the Bumper Beam Mounting Kit for the Ford Transit Custom Trail (2018+) is specially designed and engineered to fit seamlessly within the lower grille, secured to the bumper beam of the vehicle, ensuring the installation is completely secure, with extra protection against theft.
(incl. VAT £60.00)
For an OE quality, robust and entirely secure auxiliary spotlight installation, the Bumper Beam Mounting Kit for the Ford Transit Custom Trail (2018+) is specially designed and engineered to fit seamlessly within the lower grille, secured to the bumper beam of the vehicle, ensuring the installation is completely secure, with extra protection against theft.
Compatible with either our Triple-R 750 Standard or Elite, which has been newly upgraded to the latest LED technology for 2020/21. The standard variant, now with integrated with amber or white position light function for added styling to ensure your vehicle shines day and night!
The brackets are made from 3mm mild steel, with e-coat pre-treatment and satin black powder coat to guarantee your installation remains in excellent condition for years to come. The bumper beam mounting kit comes complete with fasteners and a stay-bar to avoid vibrations, keeping the installation robust and rigid.
With no compromises in component parts or production techniques, as with all Lazer products, the products are backed up by our comprehensive 5yr warranty.
- Auxiliary spotlight installation for Ford Transit Custom Trail (2018+)
- Compatible with Triple-R 750 Standard or Elite
- Fully robust and secure, with extra protection against theft
- Vehicle wiring kits and CANbus Interfaces available
- Fully road-legal
- 5-year warranty
- Made in Britain
Technical Specifications:
2x | 2x | 2x TRIPLE-R 750 | 2x | |
|---|---|---|---|---|
| Voltage Range (DC) | 10-32V | 10-32V | 10-32V | 10-32V |
| LED Life | 50,000 hours | 50,000 hours | 50,000 hours | 50,000 hours |
| Weight | 2.6 kg | 2.6 kg | 2.6 kg | 2.6 kg |
| HIGH BEAM FUNCTION | ||||
| Total Luminous Flux | 9240 Lm | 9240 Lm | 10800 Lm | 10136 Lm |
| Total Driver 'FOV' Flux † | 5266 Lm | 5572 Lm | 2484 Lm | 6680 Lm |
| Colour Temperature | 5000K | 5000K | 5000K | 5000K |
| Power Consumption | 88 Watts | 88 Watts | 104 Watts | 104 Watts |
| Current Draw (14.4V) | 6.2 Amps | 6.2 Amps | 7.4 Amps | 7.2 Amps |
| Connector | 2-Pin Superseal (+25cm Cable) | 3-Pin Superseal (+25cm Cable) | 6-Pin Superseal (+25cm Cable) | 2-Pin Superseal (+25cm Cable) |
| CERTIFICATION | ||||
| IP Rating # | IP68 | IP68 | IP68 | IP68 |
| High Beam (E9 approval) | ECE R149 - Ref: 2x 20 | ECE R112 - Ref: 2x 35 | ECE R149 - Ref: 2x 10 (Low Output Mode) | ECE R112 - Ref: 2x 12.5 (Low Output Mode) |
| Position Light (White) | N/A | ECE R7 | ECE R7 | N/A |
| EMC Certification | ECE R10 | ECE R10 | ECE R10 | ECE R10 |
| Salt Spray Test | ISO 9227 | ISO 9227 | ISO 9227 | ISO 9227 |
| Dump Load Protection | ISO 7637-2 | ISO 7637-2 | ISO 7637-2 | ISO 7637-2 |
| PHOTOMETRIC DATA | ||||
| Horizontal / Vertical Beam Angle | 40° / 20° | 19° / 18° | 28° / 16° | 42° / 13° |
| 0.25 Lux | 829m | 1225m | 1249m | 1358m |
| 0.5 Lux | 587m | 866m | 883m | 960m |
| 1 Lux | 415m | 612m | 624m | 679m |
| 3 Lux | 239m | 354m | 361m | 392m |
† - Driver FOV flux is a measure of effective lumens taking consideration of the amount of light in a driver's 'field-of-view' defined as an area +/- 45° left/right, and +/- 10° up/down. For more information – click here.
# - All Lazer products are designed to meet the requirements of IP68 testing. Every lamp produced at our UK facility is fully submerged under water prior to sending out.
